Module AS06RTD-A Delta là module mở rộng 06 ngõ vào nhiệt độ loại RTD như loại can nhiệt Pt100 / Ni100 / Pt1000 / Ni1000 / JPt100 / LGNi1000 / Cu50 / Cu100 / 0–300Ω / 0–3000Ω input impedance and Ni120 (FW V1.06 or later) dùng mở rộng cho PLC Delta AS như PLC AS228T-A, AS320...
1. Thông số kỹ thật module mở rộng AS06RTD-A
| Module Name | AS06RTD-A |
| Số ngõ vào | 06 |
| Đầu vào | Sensor type: 2-Wire & 3-Wire: Pt100: DIN 43760-1980 JIS C1604-1989; 100 Ω 3850 PPM/°C Pt1000: DIN EN60751; 1 kΩ 3850 PPM/°C Ni100/Ni1000: DIN 43760 JPt100: JIS C1604-1989 LG-Ni1000 Cu50/Cu100 |
| Nguồn cấp | 24 VDC (20.4–28.8 VDC) (-15% to +20%) |
| Kiểu kết nối | Removable terminal block |
| Overall Accuracy | 25° C/77° F: The error range allowed is ±0.5% of full scale. -20° C to +60° C/-4° F to +140° F: the error range allowed is ±1% of full scale. |
| Độ phân giải | 0.1°C / 0.1°F |
| Thời gian phản hồi | 200 ms/channel |
| Trọng lượng | 125g |
2. Thông số dải nhiệt độ đầu vào cho moduel AS06RTD-A
| Analog-to-Digital Conversion | Centigrade (°C) | Fahrenheit (°F) | Input Impedance |
| Rated Measurement Range*1 | Pt100: -180° C to +800° C Ni100: -80° C to +170° C Ni120: -80° C to +320° C Pt1000: -180° C to +800° C Ni1000: -80° C to +170° C JPt100: -180° C to +500° C LG-Ni1000: -50° C to +180° C Cu50: -50° C to +150° C Cu100: -50° C to +150° C | Pt100: -292° F to +1,472° F Ni100: -112° F to +338° F Ni120: -112° F to +608° F Pt1000: -292° F to +1,472° F Ni1000: -112° F to +338° F JPt100: -292° F to +932° F LG-Ni1000: -58° F to +356° F Cu50: -58° F to +302° F Cu100: -58° F to +302° F | 0–300 Ω 0–3000 Ω |
| Maximum Measurable Range*2 | Pt100: -200°C to 850°C Ni100: -100°C to 180°C Ni120: -80° C to +320° C Pt1000: -200°C to 850°C Ni1000: -100°C to 180°C JPt100: -200°C to 510°C LG-Ni1000: -60°C to 200°C Cu50: -50°C to 150°C Cu100: -50°C to 150°C | Pt100 : -328°F to 1,562°F Ni100: -148°F to 356°F Ni120: -112° F to +608° F Pt1000 : -328°F to 1,562°F Ni1000 : -148°F to 356°F JPt100 : -328°F to 950°F LG-Ni1000 : -76°F to 392°F Cu50 : -58°F to 302°F Cu100 : -58°F to 302°F | 0–320 Ω 0–3200 Ω |
| Average function | Range: 1-100 | ||
| Self-diagnosis | Disconnection detection |
3 .Bảng thông số các module mở rộng vào nhiệt độ cho PLC AS200, AS300
| Classification | Model Name | Description |
| AS06RTD-A | 6-channel, 2-wire/3-wire RTD Sensor type: Pt100 / Ni100 / Pt1000 / Ni1000 / JPt100 / LG Ni1000 / Cu50 / Cu100 / 0–300Ω / 0–3000Ω input impedance and Ni120 (FW V1.06 or later) Resolution: 0.1°C/0.1°F (16 bits) Conversion time: 200 ms/channel | |
| AS04TC-A | 4-channel thermocouple Sensor type: J, K, R, S, T, E, N, B, and -100 to +100 mV Resolution: 0.1°C/0.1°F (24 bits) Conversion time: 200 ms/channel | |
| AS08TC-A | 8-channel thermocouple Sensor type: J, K, R, S, T, E, N, B, and -100 to +100 mV Resolution: 0.1°C/0.1°F (24 bits) Conversion time: 200 ms/channel |
